Open Optical Line System

FR8000-OLS is a new generation of the optical line system, apply to edge data centre interconnection, particularly for IPoverDWDM applications. Provide a cost-effective and meet the transport capacity demand for more than 4T.

Inquiry Now

Share This Product:

New Generation Optical Line System

Meet the Needs Of Optical Link

Reliable Management Online Monitoring

Key Feature

Super T-bit Capacity
Extra Long Distance -2000km, Without electric repeater transmission
Support 100M to 400G mixed
Smooth network update for high bandwidth.
Whole network intelligent protection, high reliability.、
Line-side Support 1+1 Double port selecting redundancy protection、
The modular design of Power Supply, Fan Unit, Services Card for easy maintenance.

Various Format

1U/1.25U open and modularized chassis structure.
1/4 universal module slots
High-density Mux/Demux

Intelligent Network Management

Support SNMP、CLI、WEB、TELNET
Completely visual graphic information
Support electronic map positioning, fault location and isolation quickly and accurately
Support voice alarm, e-mail alerts, SMS alerts approach, real-time online remote monitoring
EMS Management platform, covering the entire Process from Plan to maintenance.
Support fault quick diagnosis, one-click export resource statements
Support Cable Fault point localization diagnosis, real-time detection cable quality.
Support OPM transmission performance scan

Chassis Specifications

System Parameters	Description
Power Supply	Support universal input 100~240V VAC or -48V VDC The dual power supplies can function in load share mode
FAN	4* FAN units
Mgmt Interface	Built-in, Support Ethernet and Console
Operation Temperature	0~50 ℃
Humidity	5% ~ 95% non-condensing; 0-10,000 ft.altitude
LEDs	Power & Module status indication
Dimension	430mm(D)355mm(W)265mm(H)
Warranty	1 year (Both Hardware and Software)
Compliance	FCC Class A, CE Class A, RoHS

Support Documents

Item	Type	Version	Release Date
Fiberroad_OLS_Product Brochure 3 MB
FR8000-OLS WebGUI Interface User Guide 1 MB
FR8000-OLS Installation Guide 636 KB
FR8000-OLS System Overview 1 MB
FR8000-OLS Maintenance Guide 473 KB
