Why a Web Smart Semi-industrial Ethernet Switch is Worth Considering
When selecting a networking solution, the Web Smart Semi-industrial Ethernet Switch stands out as a compelling option worth considering. This advanced switch offers an array of functionalities and features that cater to the specific demands of semi-industrial environments. Designed with utmost precision and reliability in mind, this switch provides seamless network connectivity while maintaining robust performance levels
Customizing Network Settings Made Easy with Web Smart Semi-industrial Interface
Its web-based management interface makes configuring and monitoring network settings effortless for users, allowing for convenient customization according to unique requirements. Web Smart Semi-industrial Ethernet Switch offers comprehensive Layer 2 management functionalities such as VLANs (Virtual Local Area Networks), QoS (Quality of Service), and Spanning Tree Protocol (STP). These features empower businesses to prioritize critical traffic flows effectively while maintaining superior network performance and stability.
Revolutionize Your Video Surveillance Network with the Web Smart Semi-Industrial Ethernet Switch
The Web Smart Semi-Industrial Ethernet Switch is a highly efficient and innovative networking solution designed to cater to the needs of small and medium-sized video surveillance networks. What sets it apart is its intelligent DIP switches, which empower users with the ability to effortlessly deploy essential functions like RSTP (Rapid Spanning Tree Protocol) and VLAN (Virtual Local Area Network). With these advanced features at their disposal, network administrators can ensure seamless operations even in dynamic environments.
QoS for Video Priority Guaranteed
Ensure that audio and video applications remain clear and lag-free by setting the priority of the traffic based on QoS.
VLAN for Network Security
A virtual network allows device grouping in different physical LANs, improving information security and reducing traffic congestion.
RSTP for Network Redundancy
Utilizing RSTP to provide redundancy in the Video Surveillance Network, as well as enhance network performance and reliability.
| Enthernet Interface | |
| Ports | 4×10/100/1000Base-T RJ45 ports, 2×100/1000Base-X SFP ports |
| Pors Mode(Tx) | Auto Negotiation Speed
Full/Half Duplex Mode Auto MDI/MDI-X Connection |
| Standards | IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseSX/LX/LHX/ZX IEEE 802.3x for flow control IEEE 802.1D-2004 for Spanning Tree Protocol IEEE 802.1w for Rapid Spanning Tree Protocol IEEE 802.1p for Class of Service IEEE 802.1Q for VLAN Tagging |
| Packet Buffer Size | 1M |
| Maximum Packet Length | Up to 9K |
| MAC Address Table | 4K |
| Transmission Mode | Store and Forward (full/half duplex mode) |
| Exchange Property | Delay time: < 7μs
Backplane bandwidth: 12Gbps |
| IGMP Group | 256 |
| VLAN ID Range | VID 1 to 4094 |
| Transmission Distance | |
| SFP Port | Depends on the optical module |
| RJ45 Port Transmission Distance | 100m（using standard CAT5/CAT5e cable） |
| Power Information | |
| Supply Current | 1.0A/48VDC |
| Working Voltage | 9-56VDC |
| Overload Protection | Yes |
| Power Reverse | Support |
| Power Consumption | Full load<10W |
| Ethernet Software Features | |
| Redundant Network | Support STP/RSTP |
| Multicast Support | Support IGMP Snooping V1/V2/V3 |
| VLAN | Support IEEE 802.1Q 4K VLAN |
| QOS | Support Port, 1Q, ACL, DSCP, CVLAN, SVLAN, DA, SA |
| Diagnostic Maintenance | Support port mirroring, Ping |
| Management Function | WEB |
| Security | Broadcast/Multicast Storm Protection, MAC filtering |
| Physical Characteristics | |
| Housing | Aluminum case |
| IP Rating | IP40 |
| Dimensions | 120mm*90mm*35mm |
| Installation Mode | DIN Rail and Wall Mounting |
| Weight | 350g |
| Working Environment | |
| Operating Temperature | -40℃~75℃ (-40 to 167 ℉) |
| Operating Humidity | 5%~90% (non-condensing) |
| Storage Temperature | -40℃~85℃ (-40 to 185 ℉) |
