Fiberroad offer a new generation of high-capacity xWDM/OTN products, apply to national, province, city backbone and other core network levels. The product line can meet the demand of more than 1.6T large capacity node, which is the most valuable transmission application platform for IDC/ISP operators to build big granularity WDM transport solutions.
NMS & Business Card
 |
 |
 |
 |
 |
 |
 |
|---|---|---|---|---|---|---|
| NMS | OTU | TMUX | EDFA | OLP | OAM | AWG |
| Part No. | FR-8010 | FR-8015 | FR-8025 | FR-8060 |
| Picture |  |
 |
 |
 |
| Client Interface | 1U Access, 1-slot | 1.25U Access, 4-slots | 2.5U Access, 7-slots | 6U Access, 15-slots |
| Power Interface | 2-Slots in back panel for power supply modules | 4-Slots in back panel | ||
| Mgmt Interface | Built-in | 1-slot in back panel | 1-slot in front panel | |
| Unit LEDs | Power & In-Use LED’s for each power supply(with use of optional LED module) | |||
| Dimensions(mm) | 430(D)x315(W)x45(H) | 430(D)x365(W)x55(H) | 430(D)x350(W)x114(H) | 430(D)x355(W)x265(H) |
| Power |
Two open bays for Chassis power modules, supporting Universal Input 100-240V VAC, or -48V VDC The dual power supplies can function in instant Fail-Ocer Mode or Load Share Mode |
|||
| Environment | 0~50CHumidity: 5%~95% non-condensing;0-10,000 ft.altitude | |||
| Net Weight | 4.2kg | 4.6kg | 5.2kg | 15.0kg |
